STANDARD LENGTHS

• 14’ - 26’

AVAILABLE WIDTH

• 96” or 102” wide with 50”, 62” or 74” Wall Height

CROSS-MEMBERS

• 4” aluminum channel cross-members (96” wide)
• 16” standard cross-member spacing
• 4” aluminum I-beam cross-members (102” wide)
• 16” standard cross-member spacing

LONGSILLS

• 14’, 16’ and 18’ lengths with 7” steel channel longsills
• 20’ – 26’ lengths with 8” steel channel long sills

FLOOR

• 1 ¼” aluminum extruded floor with 6.85” extruded aluminum front and side rails

SIDES

• .125 smooth aluminum with 2 ½” x 3” x ¼” tube-frame sides and front, smooth interior

CORNERS

• Rear extruded corner posts extend through platform for additional strength

END GATE

• 2” x 3” x ¼” aluminum tube header bar – welded in
• 38” 2 pc. rear doors with cam and a half locks – other heights available
• Hinge design allows for easy removal of gates

ROOF

• Flat roof skip welded on

LIGHTING

• Lighting and marking to FMVSS #108 Standards

LED

• LED stop, tail, turn, backup and body marker lights
