ID MODEL: 23/45

2–5 Yard Capacity

TANDARD LENGTHS

• 8’–16’ with 13” or 19” sides (boxed top rail) and 19” or 25” tailgate

WIDTHS AVAILABLE

• 88”–94”– 96” OD
• 78”– 84”– 86” ID
• (custom widths available up to 100”)

CROSSMEMBERS

• 3” structural channel steel crossmembers
• 12” standard cross-member spacing

LONGSILLS

• 6” structural channel steel longsills

CAB SHIELD

• Standard 18"

____________________________

ID MODEL: 57

5–7 Yard Capacity

STANDARD LENGTHS

• 9’–14’ available with 25” sides, standard with 31” tailgate (36” is available, also “high lift” tailgate is optional)

WIDTHS AVAILABLE

• 96” OD /  86” ID
• (custom widths available up to 100”)

CROSSMEMBERS

• 4” structural channel steel crossmembers
• 12” standard cross member spacing

LONGSILLS

• 6”–7” structural channel steel longsills

CAB SHIELD

• Standard 18"
